| Bearing No. | Loading Rating(kN) | Limiting Speed(rpm) | Boundary dimensions(mm) | ||||||||||
| Open | With shields | With seals | Cr | Cor | Grease | Oil | Inner Dia | Outer Dia | Width | Assembly Chamfer (rmin) | |||
| RS 2RS | Open Z.ZZ | Open Z.ZZ | d | D | B | ||||||||
| 16100 | 16100-Z | 16100-ZZ | 16100-RS | 16100-2RS | 5.10 | 2.38 | 17000 | 27000 | 32000 | 10 | 28 | 8 | 0.3 |
| 16001 | - | - | - | - | 5.10 | 2.38 | - | 28000 | 32000 | 12 | 28 | 7 | 0.3 |
| 16002 | - | - | - | - | 5.58 | 2.85 | - | 24000 | 28000 | 15 | 32 | 8 | 0.3 |
| 16003 | - | - | - | - | 6.00 | 3.25 | - | 22000 | 26000 | 17 | 35 | 8 | 0.3 |
| 16004 | - | - | - | - | 7.90 | 4.45 | - | 18000 | 20000 | 20 | 42 | 8 | 0.6 |
| 16005 | - | - | - | - | 8.40 | 5.15 | - | 15000 | 18000 | 25 | 47 | 8 | 0.6 |
| 16006 | - | - | - | - | 11.20 | 7.35 | - | 13000 | 15000 | 30 | 55 | 9 | 1.0 |
| 16007 | - | - | - | - | 12.20 | 8.85 | - | 11000 | 13000 | 35 | 62 | 9 | 1.0 |
| 16008 | - | - | - | - | 12.60 | 9.65 | - | 10000 | 12000 | 40 | 68 | 9 | 1.0 |
| 16009 | - | - | - | - | 14.90 | 11.40 | - | 9000 | 11000 | 45 | 75 | 10 | 1.0 |
| 16010 | - | - | - | - | 15.40 | 12.40 | - | 8500 | 10000 | 50 | 80 | 10 | 1.0 |
