6003 6003-Z 6003-ZZ 6003-RS 6003-2RS Deep Groove Ball Bearing Size 173510mm





Bearing No.					Loading Rating(kN)		Limiting Speed(rpm)			Boundary dimensions(mm)				Weight(kg)
Open	With shields		With seals		Cr	Cor	Grease		Oil	Inner Dia	Outer Dia	Width	Assembly Chamfer (rmin)	Close
Open	With shields		With seals		Cr	Cor	RS 2RS	Open Z.ZZ	Open Z.ZZ	d	D	B	Assembly Chamfer (rmin)	Close
604	604-Z	604-ZZ	604-RS	604-2RS	0.97	0.36	43000	48000	56000	4	12	4	0.2	0.0029
605	605-Z	605-ZZ	605-RS	605-2RS	1.33	0.55	38000	40000	50000	5	14	5	0.2	0.005
606	606-Z	606-ZZ	606-RS	606-2RS	1.51	0.74	34000	38000	45000	6	17	6	0.3	0.006
607	607-Z	607-ZZ	607-RS	607-2RS	2.22	0.91	32000	36000	43000	7	19	6	0.3	0.007
608	608-Z	608-ZZ	608-RS	608-2RS	3.32	1.38	28000	34000	40000	8	22	7	0.3	0.012
609	609-Z	609-ZZ	609-RS	609-2RS	3.35	1.40	24000	32000	38000	9	24	7	0.3	0.016
6000	6000-Z	6000-ZZ	6000-RS	6000-2RS	4.58	1.98	22000	31000	36000	10	26	8	0.3	0.019
6001	6001-Z	6001-ZZ	6001-RS	6001-2RS	5.10	2.38	18000	28000	32000	12	28	8	0.3	0.021
6002	6002-Z	6002-ZZ	6002-RS	6002-2RS	5.58	2.85	15000	24000	28000	15	32	9	0.3	0.026
6003	6003-Z	6003-ZZ	6003-RS	6003-2RS	6	3.25	13000	22000	26000	17	35	10	0.3	0.039
6004	6004-Z	6004-ZZ	6004-RS	6004-2RS	9.38	5.02	11000	18000	20000	20	42	12	0.6	0.069
6005	6005-Z	6005-ZZ	6005-RS	6005-2RS	10.06	5.67	9500	15000	18000	25	47	12	0.6	0.075
6006	6006-Z	6006-ZZ	6006-RS	6006-2RS	13.2	8.25	8000	13000	15000	30	55	13	1.0	0.09
6007	6007-Z	6007-ZZ	6007-RS	6007-2RS	16.2	10.3	6700	11000	13000	35	62	14	1.0	0.1
6008	6008-Z	6008-ZZ	6008-RS	6008-2RS	17	11.8	6000	10000	12000	40	68	15	1.0	0.019
6009	6009-Z	6009-ZZ	6009-RS	6009-2RS	21	14.8	5600	9000	11000	45	75	16	1.0	0.024
6010	6010-Z	6010-ZZ	6010-RS	6010-2RS	22	16.2	5000	8500	10000	50	80	16	1.0	0.026
60/22	60/22-Z	60/22-ZZ	60/22-RS	60/22-2RS	9.4	5.05	10000	13000	17000	22	44	12	0.6
60/28	60/28-Z	60/28-ZZ	60/28-RS	60/28-2RS	12.5	7.4	8400	10000	14000	28	52	12	0.6
60/32	60/32-Z	60/32-ZZ	60/32-RS	60/32-2RS	15.1	8.15	7200	8700	12000	32	58	13	1.0
